China 200mA to 100A Mini Split Core CT AC Current Sensor with M-bus
Keywords: Smart Sensor, Split Core Current Sensor, Split Core CT, M-bus CT, Current Sensor, Split Core Current Transformer, CT Sensors
Product Details
D129072 is an open core (split type) current sensor for EV Charging Pile Station. Its structural design ensure fast speed load and unload under constant power, which is greatly improve the construction efficiency and widely used in smart meter, smart grid, monitoring device, EV charger, circuit protection, and machine equipment etc. Compared with other open core current transformers and smart sensors on the market, it has the following characteristic:
With M-BUS communication, current and temperature values can be read.(voltage,current,Kwh can be customized)
Open coce (split core) structure, snap-in connection, no tools needed to remove the main circuit, low cost, easy installation, machined by mirror surface, the contact surfaces are more compact and restless.
Alarm output function: overheat alarm/overcurrent alarm. With the output function of over current or over temperature alarm, by setting the upper limit of the current or temperature.
Product Parameters
Measuring Current Range: 200mA~100A
Current accuracy : Class 1
Temp accuracy: 2℃
Rated frequency: 50~60Hz
Threading bore dimension: ≤φ12mm
Response time: 200mS
Withstand voltage: ＞3000Vac
Temp range: -20/+85℃
Application
lFor current measurement, monitoring and protection of electrical circuits and equipment
lUsed for monitoring and power management of smart meters, smart grids, charging piles, mechanical equipment
