Product Overview
MD0630T01A is a high sensititivity AC DC leakage current sensor which has the characteristics of accurate measurement, small size and integration. The leakage sensor can be set separately for AC and DC leakage. An alarm signal is generated when the set current is reached. The leakage sensor has a digital output function, which can directly read the current value of DC and AC. Which can also be called residual current sensor, residual current monitor (RCM), residual current device (RCD), differential current sensor, earth leakage detector and fault current sensor etc. Applicable for the standard IEC 62955-2018 residual current requirements for RDC-PD and adapted to DC 6mA AC 30mA test.
This residual current monitor is intended for the detection of DC and AC Residual currents in EV Charging Stations where such currents may flow under a fault condition. The RCD/RCM device may be used to detect 6mA DC or 30mA AC Residual Currents in DC, single phase or 3 phase installations, it is ideally suited for use with Electric Vehicle charging cables (Mode 2 Protection) and EV charging stations (Mode 3 Protection). When a residual fault current that exceeds the rated AC or DC level is detected, It will signal to the Smart EVSE. In addition to the use of charging piles. Also suitable for inverters, UPS, smart home, industrial machines, power distribution cabinet, photovoltaic systems etc. Protecting personal and electrical equipment safety.
Product Features
1. Complies with the DC and AC protection requirements of IEC62752 or IEC62955
2. Small Size, Integration Design, Vertical(Pin, Pin&Cable Type)/Horizontal(Cable Type) Mounting Optional
3. Integrated self-monitoring and test functions, Residual Fault Leakage Current Detection
4. AC DC Leakage Data Readable; Alarm Value Programmable; 3 Way Alarm Outputs; Digital output
5. UART Comm. with Modbus Protocol; Standard: EN 61000-6-3:2007+A1 ,EN IEC 61000-6-1:2019
6. Professional Certification: TUV(IEC62955/IEC62752/IEC61851-1/IEC62196); UL 2231-1/UL 2231-2; CE-EMC
7. Type B RCD/RCM Protection; Electrical safety at low cost (compared to Type B RCCB)
8. Robust mechanical and electrical design for harsh environmental conditions
Product Parameters
Wide voltage input: 12V±20%
Measuring current range: DC current 2-15mA; AC current 3-100mA (default threshold: DC 6mA, AC 30mA)
Accuracy : at 25℃, DC±0,2mA, AC±0.3mA
Can read current value and set alarm current value
Three outputs: DC alarm, AC alarm, AC/DC alarm
Working environment temperature: -25℃～+80℃
Plastic case, small SIP package
EV Charging Application
Leakage current measurement for OBC in-cable (mode 2) and for wall boxes (mode 3) contact and protection device
Automotive On Board Chargers (OBC) 1-3 phases 3.3 kW to 22 kW
V2X Vehicle to Everything (V2G Vehicle to Grid,V2L Vehicle to Load)
Insulated or None insulated On Board Charger
Wall box charger
