The Constitution and Principle of Current Transformer

Pulished on Sep. 09, 2020

The current transformer, as one of the main types of transformers, is often used to measure the current beyond the range of the meter. Let’s share with you the composition and principle of the current transformer。



At present, the current transformer used by people is made of iron core and winding. The principle of making the transformer is simple.The design is completed by electromagnetic induction principle.



The current transformer can convert the current on one side to 1 in the process of operation. The transformer can be installed in the environment that needs to be measured for operation with small current on the secondary side.Now the number of transformers is also increasing.When you choosing current transformer, you can combine the composition and principle to use, which can achieve good application purpose

 The Constitution and Principle of Current Transformer

Take this current transformer IVY-MF-01- 100A CT as an example.This type of current transformer is composed by advanced core & materials and widely used for measuring and testing device or meter with compact size, 500mT permanent magnetic immunity of 500mT and IEC standard compliant.For more info. plz click:

https://www.ivy-metering.com/dc-immunity-ct/ivy-mf-01-100a-ct.html



If you have anything want to know about the current transformer or any help, Please do not hesitate to contact IVY. Our over 60 engineers will provide customized and optimized service to you. Thank you for your support!
