12V Flexible Core Protective Control 3-in-1 Relay Assembly

Prouduct Details

• 3-in-1 relay module as known as 3-in-1 customized assembly.it has stable performance and long service life. Compared with power relay and magnetic latching relays, the compact relay has the following characteristics:

• Optional Maximun Switching Current; relay: 32A~200A optional, uc2/3 optional; current transformer: 7A~140A optional

• Tailored for Terminal Design;Compact Size for Cost-efficiency.

• Consists of a relay,ct and terminal block;Better Operation of Consistency.




Product Parameters

     Relay:

• Typical Choices Magnetic Latching Relay / Magnetic Immune Latching Relay

• Rated Load 250VAC

• Contact From 1A/1B

• Nominal Voltage 6 To 48 VDC

• Driving; Coils/ Motor

• External Design: Fully Customized




  CT:

• Typical Choices CT Without DC immunity/ CT With DC immunity

• Accuracy Class 0.05,0.1, 0.2

• Radio 1000/2000/2500

• Burden: 10

• External Design: Fully Customized




  Terminal Block：

• Material: PC/ABS Insulating High Strength Material

• Security: Even Grouped Close but No Risk for Loosening or Undue heating

• Terminal Hole: Fully Customized to Well-matched
