Product parameters
Product Details
D129072&D1C9002-01 are split-core current sensors with M-BUS/Wifi Communication. Its structural design ensures fast speed load and unload under constant power, which greatly improves the construction efficiency. Widely used in IOT, smart grid, electrical monitoring devices, EV chargers, circuit protection, and factory equipment, etc.
Its main features as follow:
Split core allows you to directly monitor AC current without breaking or interrupting supply.
Easy to remotely monitor devices that place in inaccessible or harsh environments.
They are easy to install
Easily snapped over pre-existing wires
Ideal for Portable electricity monitoring device
Real-time monitoring, over-current/over-temperature protection, current value can be read without secondary transformation ratio
With M-BUS communication
Product Parameters
Measuring Current Range: 200mA~100A
Current accuracy : Class 1
Temp accuracy: 2℃
Rated frequency: 50~60Hz
Threading bore dimension: ≤φ12mm
Response time: 200mS
Withstand voltage: ＞3000Vac
Temp range: -20/+85℃
Application
Sub-metering
Power factor correction devices
Metering (electrical energy meters)
Active power filter
Power measurement device for PLC
Sensing Overload Current
Ground fault detection
Digital fault recorder
In-factory display or in-home display
Electrical testing equipment and relay protection
Current, power, energy monitoring devices
