Prouduct Details
Latching relay is a new type of relay which uses magnetic principle to control circuit's on and off. Its normally open and closed state are provided completely by permanent magnet steel'working and completed the conversion of on-off state base on the triggering of a certain width pulse signal.
IVY specializes in the development and manufacturing of high-quality latching relays. We offer a line of latching relays spanning from 32A to 200A for single-phase Two-phase and three-phase switching purposes. our relays meet the industry's highest performance standards and offer the best value in the energy management market. In particular, we have developed an innovative relay switch-motor latching relay.
IM1002 is a 100A 250VAC bistable magnetic latching relay(coil 6~48vdc), widely used in smart grid, remote control, combination switch, electrical power, electronic energy meter, automatic meter reading system, solar street light control, home appliance and automatic control equipment.
Product Features
100A 250VAC switching capability
Single coil and double coils are all available
Low power consumption, Pulse driven operation
Strong resistance ability to shock and vibration
Dielectric strength 4kv(coil to contacts)
Long service life, High reliability
Environmentally friendly products(Accord RoHS)
Comply with IEC62055-31 UC2 UC3 standard
Custom assemblies available with flex wire and/or copper straps, and/or with integrated shunt
Product Parameters
Rated Load: 100A 250VAC
Contact Form: 1A/B
Rated Coil Consumption: 1.5 / 3W(20ms)
Dielectric Strength: 4kV
Contact Material AgSnO2
Compact Size: 39*30*18.5mm
Max. Switching Voltage: 277VAC
Max. Switching Power: 27700VA
Contact Resistance: <2mΩ
Pick-up Time: 20ms
Release Time: 20ms
Electrical Endurance: 5000 Cycles
Mechanical Endurance: 100000 Cycles
Temp.Rise: ≤55K When Ambient 40℃
Ambient Temperature: -40℃~70℃
Ambient Humidity: 45%~90%RH
