IVY-CT-OC-34-16 200A/40mA High Accuracy Split Core Current Transformer CT with 4-20mA Output

Share :
Product parameters

Product Detail

The split core current transformer (CT) uses high-quality ferrite as the magnetic conductive material, which has the characteristics of opening and closing, small magnetic circuit loss, and high magnetic field density. Small size, stable performance, suitable for various complex environments. In addition, it can be quickly assembled and disassembled without power off, making work more efficient. It is used for measurement and monitoring.


Product Feature

Sealed, suitable for outdoor use

Open-ended design, no need to cut off power, faster assembly and disassembly, and more efficient work

Hinge connection, the number of opening and closing is guaranteed

The contact surface of the magnetic core adopts mirror processing to make the CT contact surface closer


IVY-CT-OC-34-16 100A 200A 0.05mA~40mA Output Class 1 Class 0.5 Split Core Current Transformers for Energy Meter

Product Parameter

Rated input current 0.25A~200A

Applicable frequency range 50~60Hz

Rated output current 0.05mA~40mA

Working temperature -40℃~80℃

Transformation ratio 5000

isolation withstand voltage >3kVAC

Accuracy class 1.0 Linearity ±0.2%

Load resistance ≤5Ω  phase difference 35±7’

Internal resistance ≤580Ω  series connection hole ≤φ17mm
